I. Comprehensive Analysis and Resolution of Insufficient Discharge Capacity (Fundamental Fault)
When a compressor's discharge capacity (air delivery) fails to meet design requirements, it is typically caused by the following comprehensive reasons:
1. Insufficient Drive Power: Prime mover (diesel engine or electric motor) horsepower is inadequate.
2. Speed Reduction:
Diesel engine governor malfunction.
Clutch slippage in portable compressors.
3. Valve Failure: Broken springs, cracked or warped valve plates.
4. System Leakage: Leakage from intercoolers and vent pipes.
5. Packing Gland Leakage.
6. Clogged Intake Air Filter.
7. Excessive Piston Ring Wear.
8. Excessive Clearance Volume in First-Stage Cylinder.
9. Damaged Seals: Cylinder head gasket, valve gasket, or internal seal ring damage.
10. Poor Valve Seat Sealing: Foreign material ingress or valve plate deformation.
11. Unloader Valve Fault: Spring damage or loose push rod nut causing the valve plate to be held open.
Systematic Troubleshooting Method:
Addressing the above causes requires systematic overhaul: inspect and adjust the prime mover; repair the governor and clutch; replace damaged valve plates, springs, piston rings, and seals; clean filters and pipelines; adjust cylinder clearance; and ensure proper unloader valve function.
II. Hazards of Vibration and Systematic Elimination
Excessive compressor vibration is a precursor to serious failure. Its hazards include: increased power loss, instrument damage, accelerated component wear, induction of cylinder scoring/bearing seizure accidents, pipe cracking/loosened flanges, worsened working environment, and shortened overall machine life.
Systematic vibration elimination must address the root causes:
1. Balance Correction: Perform strict static and dynamic balance checks on all moving parts.
2. Precise Alignment: Ensure concentricity between the compressor and its driver (motor/diesel engine).
3. Foundation Isolation: The foundation must be constructed per drawings with no rigid connection to building structures.
4. Piping System Stabilization: To counteract gas pulsation, all piping must have secure supports and clamps. Cantilevered brackets need reinforcement and tight shimming.
5. Uniform Tightening: All foundation bolt torques must be consistent.
6. Ensure Stiffness: The frame (bedplate) must possess sufficient rigidity.
III. Analysis of Typical Intercooler Faults and Pressure Anomalies
The intercooler is critical for interstage cooling; its faults directly affect pressure.
1. Intercooler-Specific Faults:
Symptoms: Low cooling efficiency (high inlet water temperature, severe scaling), damaged internal baffles, ruptured or frozen water pipes.
Remedy: Adjust inlet water temperature and flow rate; clean scale/oil fouling; repair or replace baffles and water pipes.
2. Intercooler Pressure Drop:
Cause: Primarily due to leakage in the preceding stage's discharge system.
Damaged first-stage inlet/exhaust valves (valve plate, spring issues, or foreign material).
Intercooler body leakage (covers or tubes).
Leakage at connecting pipelines or gauge fittings.
Remedy: Overhaul or replace first-stage valves; perform leak detection and repair on the intercooler; tighten or repair all external connection points.
IV. Valve Fault Diagnosis Logic Based on Pressure Anomalies
Pressure is one of the most direct parameters for assessing valve condition.
1. Inlet Valve Fault Diagnosis:
Direct Symptoms: Continuous temperature rise of that inlet valve casing (exceeding 40°C), abnormal operating sounds.
Indirect Symptoms (Multi-stage Machines): If an intermediate or high-pressure cylinder inlet valve is leaking, it causes increased pressure in the preceding stage's intercooler, a decrease in the compressor's total discharge capacity, and反常 suction and discharge temperatures in that cylinder.
2. Exhaust Valve Fault Diagnosis:
Direct Symptoms: Abnormal heating of the exhaust valve cover.
Indirect Symptoms (Multi-stage Machines): Fault in the preceding stage exhaust valve leads to: decreased pressure before this stage's intake (i.e., lower preceding intercooler pressure), increased temperature of this stage's compressed gas, and reduced total compressor discharge capacity.
V. Systematic Pressure Anomaly Diagnostic Map
Analyzing anomalies at specific pressure points can precisely locate the faulty component.
Anomalous Parameter | Possible Causes (Fault Location) | Troubleshooting Direction |
First-Stage Inlet Pressure Rise | Poor first-stage inlet/exhaust valve allowing backflow; restricted inlet passage. | Overhaul/replace first-stage valves; inspect inlet piping. |
Abnormally Low First-Stage Inlet Pressure | Clogged air filter; high inlet piping resistance; inlet valve actuation mechanism sticking or spring too tight. | Clean filter; inspect piping; repair actuation mechanism; replace with appropriate spring. |
Mid-Stage Inlet Pressure Rise | Poor inlet/exhaust valve in this stage causing insufficient intake; severe piston ring leakage in preceding stage; poor efficiency of preceding stage cooler. | Overhaul this stage's valves; replace preceding stage piston rings or recondition liner; ensure preceding stage cooling efficiency. |
Mid-Stage Inlet Pressure Drop | External leakage in preceding stage discharge system (e.g., blowdown valve, bypass valve not fully closed); high resistance in piping from preceding to this stage. | Locate and seal external leaks in preceding stage; inspect and clean interstage piping. |
First-Stage Discharge Pressure Rise | Low inlet temperature, high inlet pressure; poor first-stage cooler efficiency; poor second-stage inlet/exhaust valve, impeding this stage's discharge; high resistance in piping between first and second stages. | Ensure cooling water flow; clean intercooler; overhaul second-stage valves; inspect/clean interstage piping. |
First-Stage Discharge Pressure Drop | High inlet piping resistance; poor first-stage inlet/exhaust valve; first-stage piston ring leakage; blowdown/bypass valve leakage. | Clean piping; overhaul first-stage valves; replace piston rings; fully close blowdown/bypass valves. |
Mid-Stage Discharge Pressure Rise | Poor next-stage inlet/exhaust valve; excessively high preceding stage inlet pressure; insufficient capacity of preceding stage cooler; this stage piston ring leakage; high resistance in piping to next stage. | Check next-stage valves; check preceding stage conditions and pre-cooler; replace this stage's piston rings; clear piping. |
Mid-Stage Discharge Pressure Drop | External leakage exists before the next stage's intake. | Locate and stop external leakage in the next stage's intake system. |
Final Discharge Pressure Abnormally High | High resistance in discharge valve or check valve; abnormal blockage in discharge pipeline. | Overhaul discharge valve, check valve; inspect and clear discharge pipeline. |
VI. Diagnostic Logic for Temperature Anomalies
Temperature anomalies often accompany pressure anomalies, further verifying the fault location.
1. Abnormal Rise in Suction Temperature:
High First-Stage Suction Temp: Poor first-stage suction valve causing backflow; suction line heated by ambient heat source.
High Mid-Stage Suction Temp: Poor suction valve in this stage causing backflow; low efficiency of preceding stage cooler.
Remedy: Replace faulty suction valve; relocate suction line heat source or improve ventilation; ensure efficiency of preceding stage cooler.
2. Abnormal Rise in Discharge Temperature:
High First-Stage Discharge Temp: Poor first-stage suction valve (backflow); poor second-stage suction valve (causing increased backpressure in this stage); high resistance in piping between first and second stages.
High Mid-Stage Discharge Temp: Poor efficiency of preceding or this stage cooler; poor exhaust valve in this stage (backflow); poor next-stage suction valve (causing increased backpressure in this stage); high resistance in piping to next stage.
High Second-Stage Discharge Temp (Combined Causes): High ambient temperature (>40°C); severe cylinder wear; dirty intercooler; insufficient cooling fan/pump performance; excessively small second-stage clearance volume; stuck inlet/exhaust valve plates.
Remedy: Systematically check and clean coolers, ensure air/water flow; overhaul or replace faulty valves; adjust cylinder and valve clearances; repair scored cylinder and free stuck valve plates.
3. Abnormal Drop in Discharge Temperature:
Low Mid-Stage Discharge Temp: Typically directly linked to external leakage occurring before the next stage's intake, causing this stage's discharge pressure to drop, reducing compression work and thus temperature.
Remedy: Focus on checking for and stopping external leakage in the next stage's intake system.
Conclusion
Pressure and temperature anomalies in compressors are not isolated phenomena; they are interrelated and collectively point to specific root causes of faults. Pressure anomalies often directly indicate the location of leaks, blockages, or valve failures; while temperature anomalies further verify abnormalities in the energy conversion process, often directly related to cooling effectiveness, valve sealing, and leakage. In practical diagnosis, pressure and temperature parameters should be analyzed together, following the diagnostic map provided in this article. This allows moving from the symptom to the specific component, enabling the development of accurate and efficient repair plans to ensure safe, efficient, and stable compressor operation.
