1. Primary Causes of Main and Connecting Rod Bearing Failure
Bearing seizure or "burnout" in compressors often results from a combination of the following factors:
1. Lubrication System Malfunction: Includes low oil sump level, blocked oil passages, or oil pump failure leading to insufficient lubrication. Normal oil pressure should be maintained between 150-300 kPa. Immediate shutdown and inspection are required if pressure falls below 80 kPa.
2. Improper Running Clearances: Failure to achieve the specified contact area between the bearing shell and journal (typically ≥75% with even distribution) or incorrect assembly clearance (too tight or too loose) disrupts the formation of the essential oil film.
3. Excessive Geometric Deviation: Out-of-spec ovality (out-of-roundness) of the crankshaft journal or wear/deformation of the connecting rod big end bore prevents proper bearing shell contact, creating localized high pressure and lubrication failure.
4. Component Quality Issues: Include substandard bearing alloy material, poor bonding between the alloy layer and steel backing, or excessive misalignment between main bearing bores leading to localized dry friction.
5. Insufficient Cooling: Reduced cooling system efficiency causes elevated oil temperature, lowering viscosity and hindering effective oil film formation.
2. Causes of Crankshaft Cracks and Fractures
Crankshaft cracking or fracture is a severe failure, primarily caused by:
1. Stress Concentration: Failure to maintain the designed fillet radius at journal transitions (typically r = (0.05~0.06)D, where D is the crankpin diameter) during machining or grinding.
2. Abnormal Loads: Excessive bearing clearance or bearing material loss leading to severe impact loads; excessive unit vibration potentially due to unbalanced moving parts or foundation issues.
3. Thermal Distortion & Fatigue: Localized overheating from bearing failure melting the Babbitt (white metal), causing thermal distortion; metal fatigue from long-term cyclic loading.
4. Manufacturing Defects: Internal material flaws or improper heat treatment processes.
3. Common Causes of Crankshaft Bending
Crankshaft bending is typically caused by:
1. Assembly Factors: Excessive misalignment (lack of co-axiality) between main bearing bores or excessively tight main bearing clearance restricting thermal expansion.
2. Unbalanced Forces: Failure to achieve proper dynamic balance of the piston/connecting rod assembly, counterweights, or flywheel, causing cyclical inertial forces.
3. External Factors: Uneven foundation settlement, improper long-term storage support, or accidental impact during transportation.
4. Post-Repair Issues: Assembly without verifying crankshaft straightness following major overhaul.
4. Crankshaft Repair Criteria and Timing
Repair is mandatory when the crankshaft exhibits:
1. Visible cracks (regardless of depth)
2. Excessive bending or torsional distortion
3. Deep scoring or abnormal wear on journal surfaces
4. Keyway wear affecting proper fit
Journal Wear Limit Reference:
Out-of-roundness and cylindricity (taper) of main and crankpin journals should generally not exceed 0.02 mm.
Repair should be considered when actual wear reaches 1.5 times the designed clearance value.
Common repair techniques include manual filing, precision grinding on a crankshaft grinder, and build-up welding using specialized equipment, selected based on the extent of damage.
5. Crankshaft Crack Inspection Methods
1. Non-Destructive Testing (Recommended):
Magnetic Particle Inspection (MPI): Magnetize the crankshaft and apply magnetic particles; cracks will attract particle indications.
Ultrasonic Testing (UT): Uses high-frequency sound waves to detect internal flaws.
2. Practical Methods (Without Specialized Equipment):
a. Acoustic Tap Test: Lightly tap each crank web with a brass hammer. A clear, ringing sound indicates integrity; a dull, thudding sound may suggest a crack.
b. Penetrant Method: Clean the crankshaft, apply kerosene, then dust with chalk or talcum powder. Light tapping will cause seepage at crack locations, forming a visible line.
6. Crankshaft Straightness Inspection Procedure
1. Place the cleaned crankshaft on precision V-blocks or between lathe centers.
2. Mount a dial indicator on the center main journal. Slowly rotate the crankshaft one full revolution.
3. Record the maximum dial indicator reading variation; this is the Total Indicated Runout (TIR). Actual bending deflection is half this value (TIR/2).
4. Account for the influence of journal ovality on the measurement by first checking each journal's roundness.
Straightness Standard: Typically, bending should not exceed 0.1 mm per meter of length, but always refer to the specific equipment manufacturer's specifications.
7. Key Measures to Extend Compressor Valve Life
Valves are among the most wear-prone components. Extending their service life requires a multi-faceted approach:
1. Design Optimization:
Select appropriate valve types (ring, plate, reed, etc.) based on compressor speed and operating conditions.
Use high-quality valve plate materials (e.g., Swedish valve steel, specialty stainless) with proper heat treatment.
Optimize spring design to ensure timely valve plate opening and closing.
2. Operational Practices:
Strictly control intake air cleanliness with high-efficiency air filters.
Adjust lubrication rates to prevent excessive oil from entering valves and forming carbon deposits.
Promptly drain condensate from air passages to prevent liquid slugging and corrosion.
Monitor piping vibration and install pulsation dampeners if necessary.
3. Maintenance Standards:
Periodically inspect valve plates and springs for wear.
Ensure valve seat sealing surfaces are refinished to required flatness.
Assemble valves with clean, contaminant-free components.
Summary and Key Points
Reliable piston compressor operation depends on systematic maintenance of its core components. Establishing a regular inspection regime is recommended, focusing on:
Checking bearing clearances and the lubrication system every 500-1,000 operating hours.
Inspecting crankshaft straightness and journal wear every 2,000-4,000 hours.
Establishing preventive valve replacement schedules based on the operating environment.
Maintaining complete repair records documenting replacement and repair data for critical parts.
Implementing scientific maintenance management can significantly extend compressor service life and reduce the risk of unplanned downtime. Always adhere strictly to the equipment manufacturer's technical specifications and develop customized maintenance plans based on actual operating conditions.
